Mehul Nickel Alloy is a trusted manufacturer in Dubai, UAE, specializing in high performance steel products. We offer a wide range of aluminum bronze sheets and plates, known for their exceptional durability, corrosion resistance and durability in harsh industrial environments. Our products address a variety of industries including marine, oil and gas, and aerospace. We are committed to quality products and customer satisfaction, providing customized solutions to meet specific requirements, and ensuring the highest levels of performance and reliability.
Aluminum bronze sheets and plates are basically copper, aluminum, with small amounts of iron, nickel and manganese. Typical compositions are 85-95% copper and 5-12% aluminum, providing excellent strength, corrosion resistance and corrosion resistance. Mechanical properties include high tensile strength (up to 900 MPa), good ductility and excellent fatigue resistance. This compound also exhibits exceptional resistance to seawater and oxidation. Advantages include excellent durability in harsh environments, high electrical thermal insulation, and versatility for applications such as marine, aerospace, and industrial equipment and ideal for parts a necessary and efficient.
| Specifications | ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Alloy | Aluminium | Iron | Nickel | Manganese | Zinc | Arsenic |
| CuAl5 | 4.0–6.5% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | 0.4% max. |
| CuAl8 | 7.0–9.0% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | |
| CuAl8Fe3 | 6.5–8.5% | 1.5–3.5% | 1.0% max. | 0.8% max. | 0.5% max. | |
| CuAl9Mn2 | 8.0–10.0% | 1.5% max. | 0.8% max. | 1.5–3.0% | 0.5% max. | |
| CuAl10Fe3 | 8.5–11.0% | 2.0–4.0% | 1.0% max. | 2.0% max. | 0.5% max. | |
| CuAl10Fe5Ni5 | 8.5–11.5% | 2.0–6.0% | 4.0–6.0% | 2.0% max. | 0.5% max. |
| Properties | Metric | Imperial |
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
At Mehul Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Aluminium Bronze Sheets and Plates in Dubai, UAE, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the UAE, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Aluminum bronze sheets and plates are widely used in applications requiring high strength, corrosion resistance and durability. Typical applications include marine environments for ships, moorings and marine water pumps, where corrosion resistance is required. It is used in aerospace, industrial equipment, pharmaceutical and oil and gas industries. Because of their excellent corrosion resistance, these alloys are ideal for applications such as valves, shafts and fasteners. Their oxidation resistance and superior mechanical properties make them perfect for harsh environments and heavy materials.
