Mehul Nickel Alloys is a leading manufacturer and supplier based in Dubai, UAE, specializing in high performance steel alloys. With a strong reputation for quality and innovation, the company provides a range of products to industries such as aerospace, marine, chemical, energy generation etc. Among their premium offerings, tantalum shim stands out for its superior corrosion resistance and versatility, making it ideal for critical applications in harsh environments will excellent reliability Trust Mehul Nickel Alloys provides precision engineering and solutions.
Tantalum shims are made primarily of tantalum, known for their exceptional corrosion resistance and superior texture, usually using lightweight alloys to enhance specific properties, with excellent mechanical properties so like high ductility, strength and toughness provide even at extreme temperatures. Its outstanding resistance to chemicals and oxidation makes it ideal for aerospace, medical and pharmaceutical applications. Tantalum shims are lightweight, durable and easy to manufacture, providing reliable performance in harsh environments, especially where cleanliness, heat resistance and inertness are important.
| Standards : | ASTM / ASME |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Element | R05200 (%,Max) | R05400 (%,Max) |
| C | 0.01 | 0.01 |
| O | 0.015 | 0.03 |
| N | 0.01 | 0.01 |
| H | 0.0015 | 0.0015 |
| Fe | 0.01 | 0.01 |
| Mo | 0.02 | 0.02 |
| Nb | 0.1 | 0.1 |
| Ni | 0.01 | 0.01 |
| Si | 0.005 | 0.005 |
| Ti | 0.01 | 0.01 |
| W | 0.05 | 0.05 |
| Grade | Tensile strength δbpsi (MPa)， ≥ | Yield strength δ0.2， psi (MPa)，≥ | Elongation in 1″/2″ gage length， ％， ≥ |
| RO5200/RO5400 | 30000 (207) | 20000 (138) | 25 |
| RO5252 | 40000 (276) | 28000 (193) | 20 |
| RO5255 | 70000 (481) | 60000 (414) | 15 |
| RO5240 | 40000 (276) | 28000 (193) | 20 |
At Mehul Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Dubai, UAE, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the UAE, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum shims are commonly used in applications requiring high temperature resistance and corrosion resistance. It is widely used in aerospace, electronics, and medicine. Tantalum shims are used in the manufacture of products such as heat exchangers, furnace components and semiconductor devices, where durability against extremes is required, tantalum shims are also used in special consumption tools strong chemical applications due to excellent resistance to acids such as aqua regia and sulfuric acid Makes it ideal for high performance applications.
